- 8 Microphone / line inputs with transformers - XLR / TRS combo socket
- Switchable per channel: +48 V phantom power, 80 Hz high-pass filter, phase rotation and -10 dB pad
- AD converter with 24-bit / 192kHz resolution
- 8 AES digital outputs (4x XLR)
- 2 Ethercon connections for primary and secondary Dante network
- Redundant power supply unit with lockable IEC connector (2x IEC C14)
- Frequency range: 30 - 45000 Hz
- Gain range: 60 dB
- Signal to noise ratio: 84.4 dB
- Dynamic range: 110 dB
- Maximum input level: +25.5 dBu
- USB port for firmware updates
- Design: 19"/ 2 U
