Sound engine:
- Virtual analog synthesis
- 128 voices
- 8 parts
- All sound features can be used simultaneously
Oscillators per voice:
- two Wave osc with 4096 waveforms
- two Pulse osc
- two Saw osc
- two Noise osc
- two Sub osc with several waveforms
- Hard Sync
- Hypersaw Mode
- Oscillator FM and Ring mod
- Oscillators are in two groups for better overview
- All osc per voice are available simultaneously
Per part:
- 9 simultaneously available effects
- 6-slot Mod Matrix with multiple destinations per slot
Furthermore:
- 2 filters: 12/24dB and LP/BP/HP in all configurations
- 3 envelope generators (EG)
- 3 LFOs with 128 shapes each
Extras:
- 26 patch banks (A to Z) with 128 slots each
- Arpeggiator with 128 preset patterns
- Octave Transpose
- Double Mode: layers the same sound two times and detunes them against each other
Hardware:
- Sturdy full metal case
- 256x64 pixel OLED
- Kensington Lock
Connections:
- USB 2.0 for MIDI and audio
- 5-pin DIN MIDI In/Out/Thru
- 8 balanced analog audio outputs plus Headphone out
Audio interface
- Kyra can be used as an audio interface
- Audio is transmitted to the computer via USB in up to 24bit/96kHz
- Each Part is transmitted to the computer in stereo (16 channels in total)
- 2 audio channels from the computer can be played back through Kyra
