- For Pro Tools HD/HDX, HD Native + other pro audio applications
- High-quality and powerful core for professional studio applications with versatile input and output configurations, routing and monitoring options
- Flexible concept for up to eight optional analogue or digital I/O cards up to 64 channels
- Separately available Thunderbolt 3 option for native DAW integration up to 256 channels
- 512 x 64 Summing mixers with monitor groups
- Fold downs and group formats for e.g. full Dolby Atmos configuration
- Room calibration via integrated SPQ speaker processing with 256 filters on 16 channels and delay management with up to 150 ms per channel
- Routing matrix with 4096x4096 points for signal distribution of all connected audio devices
- Calibration and control of the MTRX II with the supplied DADman and Pro | Mon monitor control software
- 64 Channels of DigiLink at all sample rates for integration into Pro Tools HD / HDX systems
- 64 Channels of MADI I/O at 44.1/48 kHz
- 32 Channels at 88.2/96 kHz or 12 channels at 176.4/192 kHz
- 256 Channels Dante I/O at 44.1/48 kHz
- 128 Channels at 88.2/96 kHz or 64 channels at 176.4/192 kHz (IP core)
- 128 Channels SPQ speaker processing
- System synchronisation via Word Clock / Video Black Burst (VBB) I/O on BNC connectors or Dante Sync or digital inputs
- Supported sample rates from 44.1 - 384 kHz
- Dimensions (W x D x H): 485 x 360 x 90 mm
- Weight: 4 kg
- Incl. Pro | Mon 3 monitoring control, DADman software
- Incl AC power cable
